Falcon Parameters Appendix A
A-4
Modulation Configuration DHW forced rate Service 0 35% 100% % 201
Modulation Configuration DHW forced rate time Service 0m 0s mmm ss 202
Modulation Configuration Firing rate control User A:Automatic firing 204
Modulation Configuration Manual firing rate User 0 30% 100% % 205
Modulation Configuration CH slow start enable Service Enabled 477
Modulation Configuration DHW slow start enable Service Disabled 478
Modulation Configuration Slow start ramp Service 0 5% 100% % per min 479
Modulation Configuration Slow start degrees Service 20 oF 480
Modulation Configuration Rate assigned to 0V/4mA (Min
mod > 80%)
User 100% 0 to
100%
534
Modulation Configuration Analog input hysteresis Service .2 mA 543
Modulation Configuration Analog rate tracking User A:Analog rate tracking disabled 667
Pump Configuration CH pump output Service A:No pump assignment 272
Pump Configuration CH pump control Service A:Automatic pump control 273
Pump Configuration CH pump overrun time Service 5m 0s mmm ss 274
Pump Configuration CH pump frost protection overrun
time
Service 60m 0s mmm ss 275
Pump Configuration DHW pump output Service A:No pump assignment 276
Pump Configuration DHW pump control Service A:Automatic pump control 277
Pump Configuration DHW pump overrun time Service 1m 0s mmm ss 278
Pump Configuration DHW pump frost protection
overrun time
Service 60m 0s mmm ss 279
Pump Configuration DHW pump start delay Service 1m 0s mmm ss 280
Pump Configuration Boiler pump output Service C:Pump assigned to terminal B 281
Pump Configuration Boiler pump control Service A:Automatic pump control 282
Pump Configuration Boiler pump overrun time Service 5m 0s mmm ss 283
Pump Configuration Auxiliary 1 pump output Service D:Pump assigned to terminal C 284
Pump Configuration Auxiliary 1 pump control Service A:Automatic pump control 285
Pump Configuration System pump output Service A:No pump assignment 287
Pump Configuration System pump control Service A:Automatic pump control 288
Pump Configuration System pump overrun time Service 15m 0s mmm ss 289
Pump Configuration Pump exercise interval Service 0 Days 290
Pump Configuration Pump exercise time Service 0m 0s mmm ss 291
Pump Configuration CH pump start delay Service 0m 10s mmm ss 292
Pump Configuration Boiler pump start delay Service 0m 10s mmm ss 293
Pump Configuration System pump start delay Service 0m 0s mmm ss 294
Pump Configuration Auxiliary 1 pump start delay Service 0m 20s mmm ss 295
Pump Configuration CH pump options 1 Service 0x0324 296
Pump Configuration CH pump options 2 Service 0xC048 297
Pump Configuration DHW pump options 1 Service 0x0048 298
Pump Configuration DHW pump options 2 Service 0x4190 299
Pump Configuration Boiler pump options 1 Service 0x0002 300
Pump Configuration Boiler pump options 2 Service 0x4009 301
Pump Configuration System pump options 1 Service 0x0360 302
Pump Configuration System pump options 2 Service 0x8009 303
Pump Configuration Auxiliary 1 pump overrun time Service 5m 30s mmm ss 752
Pump Configuration Auxiliary 1 pump options 1 Service 0x0262 753
Pump Configuration Auxiliary 1 pump options 2 Service 0x4019 754
Pump Configuration Auxiliary 2 pump output Service B:Pump assigned to terminal A 755
Pump Configuration Auxiliary 2 pump control Service A:Automatic pump control 756
Pump Configuration Auxiliary 2 pump start delay Service 0m 0s mmm ss 757
Pump Configuration Auxiliary 2 pump overrun time Service 3m 0s mmm ss 758
Pump Configuration Auxiliary 2 pump options 1 Service 0x0003 759
Pump Configuration Auxiliary 2 pump options 2 Service 0x4000 760
Statistics Configuration Burner cycle count Read
Only
0Cycles128
Statistics Configuration Burner run time Read
Only
0Hours130
Statistics Configuration CH pump cycle count Service 0 Cycles 132
Statistics Configuration DHW pump cycle count Service 0 Cycles 134
Statistics Configuration System pump cycle count Service 0 Cycles 136
Statistics Configuration Boiler pump cycle count Service 0 Cycles 138
Statistics Configuration Auxiliary 1 pump cycle count Service 0 Cycles 140
Table A-1 CFLC Falcon Parameters (Continued)
Parameter Group Parameter Name Access* Min
range
Default Setting Max.
Range
Parameter
Units
Modbus
Register (dec)
