Appendix A Falcon Parameters
A-5
Statistics Configuration Auxiliary 2 pump cycle count Service 0 Cycles 146
High Limits Outlet high limit setpoint Service 32 240 250 oF 464
High Limits Outlet high limit response Read
Only
A:Lockout 465
High Limits DHW high limit enable Service A:No high limit 474
High Limits DHW high limit setpoint Service 32 NoValue 250 oF 475
High Limits DHW high limit response Service B:Recycle && hold 476
High Limits Outlet high limit enable Read
Only
B:Dual sensor safety high limit 484
Stack Limit Stack limit enable Service A:No stack high limit 466
Stack Limit Stack limit setpoint Service 250 266 oF 467
Stack Limit Stack limit response Service A:Lockout 468
Stack Limit Stack limit delay Service 5m 0s mmm ss 469
Delta-T Limits Delta-T inlet/outlet enable Service D:Enable both Delta-T and
inversion
470
Delta-T Limits Delta-T inlet/outlet degrees Service 50 oF 471
Delta-T Limits Delta-T response Service C:Recycle && delay with retry limit 472
Delta-T Limits Delta-T delay Service 5m 0s mmm ss 473
Delta-T Limits Delta-T retry limit Service 3 100 485
Delta-T Limits Delta-T rate limit enable Service Enabled 486
Delta-T Limits Delta-T inverse limit time Service 5m 0s 30m
0s
mmm ss 487
Delta-T Limits Delta-T inverse limit response Service C:Recycle && delay with retry limit 488
T-rise Limit Outlet T-rise enable Service Disabled 481
T-rise Limit T-rise degrees Service 10 oF 482
T-rise Limit T-rise delay Service 3m 0s mmm ss 483
T-rise Limit T-rise response Service C:Recycle && delay with retry limit 492
T-rise Limit T-rise retry limit Service 10 493
Anticondensation
Configuration
CH anticondensation enable Service Disabled 496
Anticondensation
Configuration
CH anticondensation setpoint Service 130 230 oF 497
Anticondensation
Configuration
DHW anticondensation enable Service Enabled 499
Anticondensation
Configuration
DHW anticondensation setpoint Service 130 230 oF 500
Anticondensation
Configuration
Anticondensation > Forced rate User Yes/True/On 502
Anticondensation
Configuration
Anticondensation > Slow start User Yes/True/On 502
Anticondensation
Configuration
Anticondensation > Outlet limit User No/False/Off 502
Anticondensation
Configuration
Anticondensation > Stack limit User No/False/Off 502
Anticondensation
Configuration
Anticondensation priority Service 502
Anticondensation
Configuration
Anticondensation > Delta-T User No/False/Off 502
Anticondensation
Configuration
Frost protect anticondensation
enable
Service Disabled 503
Frost Protection Configuration CH frost protection enable Service Disabled 528
Frost Protection Configuration DHW frost protection enable Service Disabled 529
Frost Protection Configuration Outdoor frost protection setpoint Service 32 oF 530
Frost Protection Configuration LL frost protection enable Service Disabled 532
Frost Protection Configuration LL frost protection rate Service 0 20% 100% % 533
Annunciation Configuration Annunciation enable Read
Only
Enabled 304
Annunciation Configuration Annunciator 1 location OEM E:Other annunciation 306
Annunciation Configuration Annunciator1 short name OEM A1 307
Annunciation Configuration Annunciator 1 long name OEM AIR SWITCH 309
Annunciation Configuration Annunciator 2 location Service A:No annunciation for this terminal 319
Annunciation Configuration Annunciator2 short name Service A2 320
Annunciation Configuration Annunciator 2 long name Service AUX LOW WATER 322
Annunciation Configuration Annunciator 3 location OEM D:Interlock circuit 332
Annunciation Configuration Annunciator3 short name OEM A3 333
Annunciation Configuration Annunciator 3 long name OEM LOW WATER 335
Table A-1 CFLC Falcon Parameters (Continued)
Parameter Group Parameter Name Access* Min
range
Default Setting Max.
Range
Parameter
Units
Modbus
Register (dec)
