Appendix B VSD Parameters
B-7
Basic
Program
*P31 Motor NP Volts Rated Volts Motor NPL Volts
*P32 Motor NP Hertz 60 Hz Motor NPL Hertz
*P33 Motor OL Current Rated Amps Motor NPL F.L. Amps x 1.15
*P34 Minimum Freq 0.0 Hz See Table 1.1
*P35 Maximum Freq 60 Hz See Table 1.1
*P36 Start Source 2-W Lvl Sens 2 Wire, 002
P37 Stop Mode Coast,CF
COAST,CF
P38 Speed Reference Analog In1
OK
P39 Accel Time 1
20.00 Secs OK
P40 Decel Time 1
20.00 Secs OK
P41 Reset to Defaults Ready/Idle OK
P42 Auto Mode Hnd-Off-Auto No Funtion - 000
Terminal
Block
T51 Digital In 1 Sel Purge OK
T52 Digital In 2 Sel Local OK
T53 Digital In 3 Sel Clear Fault OK
T54 Digital In 4 Sel Comm Port OK
*T55 Relay Out 1 Sel Ready/Fault Above Freq, 006
*T56 Relay Out 1 Level 0.0 16.5
T57 Not Used
T58 Relay 1 On Time 0.0 Secs OK
T59 Relay 1 Off Time 0.0 Secs OK
*T60 Relay Out 2 Select Motor Running Above Freq, 006
*T61 Relay Out 2 Level 0.0 40
T62 Not Used
T63 Relay 2 On Time 0.0 Secs OK
T64 Relay 2 Off Time 0.0 Secs OK
T65 Opto Out Sel At Frequency OK
T66 Opto Out Level 0.0 OK
T67 Not Used
T68 Opto Out Logic 0 OK
*T69 Analog In 1 Sel 2 4-20 mA, 001
T70 Analog In 1 Lo 0.0% OK
T71 Analog In 1 Hi 100.0% OK
T72 Analog In 1 Loss Disabled OK
T73 Analog In 2 Sel 2 OK
T74 Analog In 2 Lo 0.0% OK
T75 Analog In 2 Hi 100.0% OK
T76 Analog In 2 Loss Disabled OK
T77 Sleep-Wake Sel Disabled OK
T78 Sleep Level 10.0% OK
T79 Sleep Time 0.0 Secs OK
T80 Wake Level 15.0% OK
T81 Wake Time 0.0 Secs OK
T82 Analog Out1 Sel 0 OK
T83 Analog Out1 High 100.0% OK
T84 Analog Out1 Setpt 0.0% OK
T85 Analog Out2 Sel 1 OK
T86 Analog Out2 High 100.0% OK
T87 Analog Out2 Setpt 0.0% OK
CFLC VSD Parameters - PF400 (Continued)
Par. No. Parameter Name Default Value W/ CFLC
