VSD Parameters Appendix B
B-8
Communic
ations
C101 Language English OK
C102 Comm Format RTU 8-N-1 OK
C103 Comm Data Rate 9600 OK
C104 Comm Node Addr 100 OK
C105 Comm Loss Action Fault OK
C106 Comm Loss Time 5.0 Secs OK
C107 Comm Write Mode Save OK
Advanced
Program
A141 Purge Frequency 5.0 Hz OK
A142 Internal Freq 60.00 Hz OK
A143 Preset Freq 0 0.0 Hz OK
A144 Preset Freq 1 5.0 Hz OK
A145 Preset Freq 2 10.0 Hz OK
A146 Preset Freq 3 20.0 Hz OK
A147 Accel Time 2 30.00 Secs OK
A148 Decel Time 2 30.00 Secs OK
A149 S Curve % 20% Disabled OK
A150 PID Trim Hi 60.00 Hz OK
A151 PID Trim Lo 0.0 Hz OK
A152 PID Ref Sel PID Disabled OK
A153 PID Feedback Sel Analog In 1 OK
A154 PID Prop Gain 1 OK
A155 PID Integ Time 2.0 Secs OK
A156 PID Diff Rate 0.00 OK
A157 PID Setpoint 0.0% OK
A158 PID Deadband 0.0% OK
A159 PID Preload 0.0 Hz OK
A160 Process Factor 30.0 OK
A161 Not Used
A162 Not Used
*A163 Auto Restart Tries 0 2
*A164 Auto Restart Delay 1.0 Secs 2
A165 Start At Power Up Disabled OK
A166 Reverse Disable Rev Disabled OK
*A167 Flying Start Enable Disabled Enabled, 001
A168 PWM Frequency 4.0 kHz OK
A169 PWM Mode 2-Phase OK
A170 Boost Select 45.0, VT OK
A171 Start Boost 2.5% OK
A172 Break Voltage 25.0% OK
A173 Break Frequency 15.0 Hz OK
A174 Maximum Voltage Rated Volts OK
A175 Slip Hertz @ FLA 2.0 Hz OK
A176 DC Brake Time 0.0 Secs OK
A177 DC Brake Level Rated Amps x 0.05 OK
A178 DC Brk Time @Strt 0.0 Secs OK
A179 Current Limit 1 Rated Amps x 1.1 OK
A180 Current Limit 2 Rated Amps x 1.1 OK
A181 Motor OL Select No Derate OK
A182 Drive OL Mode Both-PWM 1st OK
A183 SW Current Trip 0.0 Disabled OK
A184 Load Loss Level 0.0 Disabled OK
CFLC VSD Parameters - PF400 (Continued)
Par. No. Parameter Name Default Value W/ CFLC
