Appendix B VSD Parameters
B-9
A185 Load Loss Time 0 Secs OK
A186 Stall Fault Time 60 Seconds OK
A187 Bus Reg Mode Enabled OK
A188 Skip Frequency 1 0 Hz OK
A189 Skip Freq Band 1 0.0 Hz OK
A190 Skip Frequency 2 0 Hz OK
A191 Skip Freq Band 2 0.0 Hz OK
A192 Skip Frequency 3 0 Hz OK
A193 Skip Freq Band 3 0.0 Hz OK
*A194 Compensation Electrical Disable, 000
A195 Reset Meters Ready/Idle OK
A196 Testpoint Select 1024 OK
A197 Fault Clear Ready/Idle OK
A198 Program Lock Unlocked OK
*A199 Motor NP Poles 4 2
*A200 Motor NP Amps Drive Rated Amps SAME AS P-33
Advanced
Display
d301 Control Source Read Only
d302 Contrl In Status Read Only
d303 Comm Status Read Only
d304 PID Setpnt Displ 0.0%
d305 Analog In 1 0.0%
d306 Analog In 2 0.0%
d307 Fault 1 Code Read Only
d308 Fault 2 Code Read Only
d309 Fault 3 Code Read Only
d310 Fault 1 Time-hr Read Only
d311 Fault 1 Time-min Read Only
d312 Fault 2 Time-hr Read Only
d313 Fault 2 Time-min Read Only
d314 Fault 3 Time-hr Read Only
d315 Fault 3 Time-min Read Only
d316 Elapsed Time-hr Read Only
d317 Elapsed Time-min Read Only
d318 Output Powr Fctr Read Only
d319 Testpoint Data Read Only
d320 Control SW Ver Read Only
d321 Drive Type Read Only
d322 Output Speed Read Only
d323 Output RPM Read Only
CFLC VSD Parameters - PF400 (Continued)
Par. No. Parameter Name Default Value W/ CFLC
