History records
Following table does not contain Wrn, Sd and Fls messages from external units.
Events specification
Protection
type
Information available on
binary output
Alarms
Wrn Analog input 1 to 8
WRN
YES
Sd Analog input 1 to 8
SD
YES
ID-DCU MARINE Binary input 1
to 14
Configurable
YES
ID-DCU MARINE Battery voltage
<, >
WRN
YES
ID-RPU A Battery voltage <, >
WRN
ID-RPU B Battery voltage <, >
WRN
Battery flat
WRN
Start fail
WRN
YES
ParamFail
NONE
Overspeed
SD
YES
Underspeed
WRN
YES
EmergencyStop
SD
Pickup fail
WRN
Stop fail
WRN
YES
WrnServiceTime
WRN
ChrgAlternFail
WRN
YES
Fault reset
LOC mode ON
YES
LOC mode OFF
Harbour mode ON
YES
Harbour mode OFF
SecBattery
YES
ID-RPU Sd1 Broken wire
WRN
ID-RPU Sd2 Broken wire
WRN
ID-RPU Sd3 Broken wire
WRN
ID-RPU Sd4 Broken wire
WRN
ID-RPU Sd5 Broken wire
WRN
ID-RPU Stop sol.Broken wire
WRN
ID-RPU Fuel sol.Broken wire
WRN
Emergency stop
