Sensors availability
Sensors available on ID-DCU MARINE
AI1 – AI4
Resolution
Sensor range
HW jumper
Pt1000/°C, Ni1000/°C,
Pt1000/°F, Ni1000/°F
Fix, not configurable
Resistance: 3-4
4-20 mA active,
±20 mA active (measures + only)
Adjustable -
see Hint
below.
For 20 mA input
Current: 1-2
0-250 Ω, 0-2400 Ω
For 250 or 2400 Ω
Input
Resistance: 3-4
Tristate
Resistance: 3-4
0 to 4VDC
Adjustable
Voltage: 2-3
Sensors available on ID-DCU MARINE
AI5 – AI8
Resolution
Sensor range
HW jumper
Pt100/°C, Pt1000/°C, Ni100/°C, Ni1000/°C,
Pt100/°F, Pt1000/°F, Ni100/°F, Ni1000/°F
Fix, not configurable
Resistance: 3-4
Thermocpl J/°C, Th…. K/°C, Th…L/°C,
Thermocpl J/°F, Th…. K/°F, Th…L/°F
Fix, not configurable
Voltage: 2-3
4-20 mA active, ±20 mA active
Adjustable -
see Hint
below.
For 20 mA input
Current: 1-2
0-250 Ω, 0-2400 Ω
For 250 or 2400 Ω
input
Resistance: 3-4
±1 V, 0-100mV
For 1V or 100mV
Voltage: 2-3
Tristate
Resistance: 3-4
0 to 5VDC
Adjustable
Voltage: 2-3
