Develop D 16G - Disassembly;Adjustment Miscellaneous

D-40
5. MISCELLANEOUS
5-1. Removal of the Mechanical Counter (Option)
1. Remove the Right Cover.
☞ D-7
2. Remove the Rear Cover.
☞ D-7
3. Unplug one connector on the Controller/Mechani-
cal Control Board.
4980D055AA
4. Remove the Relay Harness.
4980D056AA
5. Remove the screw, and then remove the
Mechanical Counter.
4137U003AA
