Develop D 16G - Removal of the Interface Board

D-11
(3) Removal of the Interface Board
1. Remove the Rear Cover.
☞ D-7
2. Unplug the three connectors on the Controller/
Mechanical Control Board.
4980D063AA
3. Remove the two screws, and then remove the
Left Rear Cover.
4980U044AA
4. Remove the three screws, and then remove the
Circuit Board and Metal Bracket.
4980E008AA
5. Remove the two screws, and then remove the
Protective Metal Bracket for the Interface Board.
4980D065AA
6. Remove the seven screws, and then remove the
Interface Board.
4980D066AA
