Develop D 16G - Print Head (PH) Details

M-18
9. PRINT HEAD (PH)
9-1. Construction
• The laser beam light emitted from the Print Head is used to scan the image as driven by
the Polygon Motor.
Polygon Mirror
G2 Lens
SOS Mirror
SOS Sensor
G1 Lens
Semiconductor Laser
4136M005AA
1st Mirror
2nd Mirror
