T- 1 5
(2) C0210: H.V. abnormal
<Detection Timing>
<Troubleshooting Procedures>
Description
• The Drum Charge Monitor Voltage (HVC_MON) signal falls outside a predetermined
range at any time after the lapse of a predetermined period of time after the Power
Switch has been turned ON.
• The Image Transfer Voltage Monitor signal (T_MON_V) and Image Transfer Current
Monitor signal (T_MON_I) fall outside a corresponding predetermined range.
Relevant Electric Parts
Fusing Unit Controller/Mechanical Control Board (PWB-P)
Step Action Ref. Page
WIRING DIAGRAM
Control Signal
Location
(Electric Parts)
1 Replace Fusing Unit. –– –
2 Replace PWB-P. –– –
To Next Page
