Develop D 16G - C14 A3: IR Lamp Malfunction

T- 2 2
(13) C14A3: IR lamp malfunction
<Detection Timing>
<Troubleshooting Procedures>
Description
• The luminosity level of the Exposure Lamp is not stabilized within the predetermined
period of time.
Relevant Electric Parts
IR Unit Controller/Mechanical Control Board (PWB-P)
Step Action Ref. Page
WIRING DIAGRAM
Control Signal
Location
(Electric Parts)
1 Check the connection of the connectors,
and then correct them if necessary.
–– –
3 Replace PWB-P. –– –
4 Replace the Scanner Assy. –– –
