Develop D 16G - Operating Sequence Details

M-6
5. OPERATING SEQUENCE
5-1. Print Start Sequence
(1) When the pre-start control is not provided
Start key
ON
Polygon
Motor
Main
Motor
Paper Take-
Up Solenoid
/S1
Drum Charge
Output
Exposure
Output
Develop-
ing Output
Tra ns fer
Output
Drum charge DC Drum charge DC
Charge
Reverse bias
Charge
Reverse bias
Unexposed area
output
Negative output
ON
Negative output
4980M013AA
