T- 9
2-4. Misfeed Detection Timing and Troubleshooting Procedures
(1) Paper Take-Up/Transport Misfeed
<Detection Timing>
<Troubleshooting Procedures>
Type Description
MP tray Pick-
up Jam
The Paper Take-Up Switch does not turn on after the predetermined period
of time has elapsed after paper take-up began.
2nd tray Pick-
up Jam
Bypass tray
Pick-up Jam
Separator
Jam
The Exit Sensor is not blocked after the predetermined period of time has
elapsed after the Paper Take-Up Switch is turned on.
The Paper Take-Up Switch is not turned off after the predetermined period
of time has elapsed after the Paper Take-Up Switch is turned on.
Relevant Electrical Parts
Paper Take-Up Switch (S1)
Exit Sensor (PS1)
Paper Take-Up Solenoid (SL1)
Controller/Mechanical Control Board (PWB-P)
Step Action Ref. Page
WIRING DIAGRAM
Control Signal
Location
(Electric Parts)
1 Initial checks ☞ T- 6 ––
2 SL1 solenoid check ☞ T- 2 PWB-P MPJ3P-2 I-6 to 7
3 S1 switch check ☞ T- 2 PWB-P
MPJ10P-2
G-8 to 9
4 PS1 sensor check ☞ T- 1 PWB-P
MPJ8P-3
E to F-7 to 8
5 Replace PWB-P. –– –
To Next Page
