Develop D 16G - Page 76

D-8
No. Name Removal Procedure
1 Original Cover Open the Original Cover → Pull it straight up.
2
Upper Cover Assy.
(Original Glass)
Remove the Original Cover. → Remove the Control
Panel. → Remove the six screws, and remove the Upper
Cover Assy. (Original Glass).
☞ D-18
3 Control Panel
Open the Original Cover. → Remove the three screws,
unplug the connector and the flat cable, and remove the
Control Panel.
☞ D-10
4 Exit tray While pressing out one side, remove the Exit tray.
5 Front Door
Open the Front Door. → While pressing in one side,
remove the Front Door.
6 Bypass Tray –
7Tray1
Hold down the main unit with one hand and pull Tray1 off
toward you.
8Left Cover
Open the Front Door. → Remove the screw, unhook the
six tabs, and remove the Left Cover.
9 Right Cover
Open the Front Door. → Remove the two screws, unhook
the four tabs, and remove the Right Cover.
10 Rear Cover Remove the five screws, and remove the Rear Cover.
