D-13
9. Remove the three screws, unhook the tab, and
then remove the Left Rear Frame.
4980D009AB
10. Remove the three screws from the Left Rear
Frame.
4980D071AA
11. Remove the four screws, and then remove the
Metal Bracket.
4980D072AA
12. Remove the two screws, unhook the tab, and
then remove the Left Rear Frame.
4980D010AC
13. Remove the Upper Left Cover.
14. Remove the two screws, and then remove the
Upper Right Cover and Protective Metal Bracket.
NOTE
• The Protective Metal Bracket is tightened together
with the Upper Right Cover.
4980E001AC
