D-22
6. Unhook two tabs and remove the tray.
4980D027AC
7. Remove the Multi purpose Tray Paper Empty
Sensor.
4980D028AB
8. Remove the Multiple Bypass Tray Paper Empty
Sensor.
4980D029AB
9. Remove the Toner Empty detection sensor.
4980D030AA
