SYSTEM C OMPONENTS
VF8 DELTA/DELTA XL/KAPPA B-13
Infinity Docking Station (IDS)
Power Adapter (Monitor and IDS)
Physical Attributes
Connections: Delta/Delta XL series, 15” VGA Display (remote display), R50
Recorder, Infinity network, MIB, ISD, CAN bus, Communication
Ports 1 & 2
Cooling: Convection
Size (W x D x H): 228 x 210 x 102 (9 x 8.25 x 4 in)
Weight: 2kg (4.5lbs)
Electrical Specifications
Input voltage range: +12 VDC, +15 %, –3%
Mains frequency: Not applicable
Power consumption: 0.7 A @12 V with no devices attached
Power output: 10.1 A @12 V with all devices attached
Protection class: Internally powered (per IEC 60601-1) and for use with specified
Class 1 power supplies.
Chassis leakage current: 100 μA
Mode of operation: Continuous
Environmental Requirements
Temperature range: Operating: 10 to 40 °C (50 to 104 °F)
Storage: –20 to 50 °C (–4 to 122 °F)
Relative humidity: Operating: 20 to 90 %, non-condensing
Storage: 10 to 95 % (with packaging)
Atmospheric pressure: Operating: 525 to 795 mmHg (70 to 106 kPa)
Storage: 375 to 795 mmHg (50 to 106 kPa)
Physical Attributes
Connections: AC Power Connector, DC Power Cable/Connector, Ground/
Potential Equalization Connector
Cooling: Convection
Size (W x D x H): 135 x 111 x 270 mm (5.3 x 4.4 x 10.6 in)
Depth is 71 mm (2.8 in) without the mounting bracket.
Weight: 1.85 kg (4.1 lbs)
Power requirements: 100 to120 V AC, 3.4 A or 200 to 240 V AC,1.7 A
(switch selectable)
Mains frequency: 50/60 Hz
Power output: +13V DC, 10.8 A

Dräger Infinity Delta Specifications

General

Display Size	10.4 inch
Resolution	800 x 600 pixels
Battery Type	Lithium-ion
Parameters Monitored	ECG, SpO2, NIBP, Invasive Blood Pressure, Temperature, CO2, Cardiac Output
ECG	Yes
SpO2	Yes
NIBP	Yes
Invasive Blood Pressure	Yes
Temperature	Yes
CO2	Yes
Cardiac Output	Yes
Power Supply	100 to 240 V AC, 50/60 Hz
Connectivity	WLAN
Operating Temperature	0 to 40 °C
Storage Temperature	-20 to 60 °C
Humidity	15 to 95 % relative humidity, non-condensing
Alarms	Audible and visual alarms
