Edge-Core ES4626F

Configuring 802.1X Port Authentication
6-23
6
CLI – This example sets the 802.1X parameters on port 2. For a description of the
additional fields displayed in this example, see “show dot1x” on page 25-32.
Console(config)#interface ethernet 1/2 27-1
Console(config-if)#dot1x port-control auto 25-28
Console(config-if)#dot1x re-authentication 25-30
Console(config-if)#dot1x max-req 5 25-27
Console(config-if)#dot1x timeout quiet-period 40 25-31
Console(config-if)#dot1x timeout re-authperiod 5 25-31
Console(config-if)#dot1x timeout tx-period 40 25-32
Console(config-if)#end
Console#show dot1x 25-32
Global 802.1X Parameters
system-auth-control: enable
802.1X Port Summary
Port Name Status Operation Mode Mode Authorized
1/1 disabled Single-Host ForceAuthorized yes
1/2 enabled Single-Host Auto yes
.
.
.
1/25 disabled Single-Host ForceAuthorized n/a
1/26 disabled Single-Host ForceAuthorized n/a
802.1X Port Details
802.1X is disabled on port 1/1
802.1X is enabled on port 1/2
reauth-enabled: Disable
reauth-period: 3600
quiet-period: 60
tx-period: 30
supplicant-timeout: 30
server-timeout: 10
reauth-max: 2
max-req: 2
Status Authorized
Operation mode Single-Host
Max count 5
Port-control Auto
Supplicant 00-e0-29-94-34-65
Current Identifier 7
Authenticator State Machine
State Authenticated
Reauth Count 0
Backend State Machine
State Idle
Request Count 0
Identifier(Server) 6
Reauthentication State Machine
State Initialize
.
.
.
.
802.1X is disabled on port 1/26
Console#
