IP Routing
19-14
19
Web - Click IP, ARP, Other Addresses.
Figure 19-6 ARP Other Addresses
CLI - This router uses the Type specification “other” to indicate local cache entries in
the ARP cache.
Displaying ARP Statistics
You can display statistics for ARP messages crossing all interfaces on this router.
Console#show arp 41-34
Arp cache timeout: 1200 (seconds)
IP Address MAC Address Type Interface
--------------- ----------------- --------- -----------
10.1.0.0 ff-ff-ff-ff-ff-ff other 1
10.1.0.11 00-11-22-33-44-55 static 1
10.1.0.12 01-02-03-04-05-06 static 1
10.1.0.19 00-10-b5-62-03-74 dynamic 1
10.1.0.253 00-00-ab-cd-00-00 other 1
10.1.0.255 ff-ff-ff-ff-ff-ff other 1
Total entry : 6
Console#
Table 19-2 ARP Statistics
Parameter Description
Received Request Number of ARP Request packets received by the router.
Received Reply Number of ARP Reply packets received by the router.
Sent Request Number of ARP Request packets sent by the router.
Sent Reply Number of ARP Reply packets sent by the router.
