Virtual Router Redundancy Protocol Commands
40-7
40
Example
This example displays the full listing of status information for all groups.
This example displays the brief listing of status information for all groups.
Console#show vrrp
Vlan 1 - Group 1,
State Master
Virtual IP Address 192.168.1.6
Virtual MAC Address 00-00-5E-00-01-01
Advertisement Interval 5 sec
Preemption Enabled
Min Delay 10 sec
Priority 1
Authentication SimpleText
Authentication Key bluebird
Master Router 192.168.1.6
Master Priority 255
Master Advertisement Interval 5 sec
Master Down Interval 15
Console#
Table 40-3 show vrrp - display description
Field Description
State VRRP role of this interface (master or backup)
Virtual IP
address
Virtual address that identifies this VRRP group
Virtual MAC
address
Virtual MAC address derived from the owner of the virtual IP address
Advertisement
interval
Interval at which the master virtual router advertises its role as the master
Preemption Shows whether or not a higher priority router can preempt the current acting master
Min delay Delay before a router with a higher priority can preempt the current acting master
Priority Priority of this router
Authentication Authentication mode used to verify VRRP packets
Authentication
key
Key used to authenticate VRRP packets received from other routers
Master Router IP address of the router currently acting as the VRRP group master
Master priority The priority of the router currently acting as the VRRP group master
Master
Advertisement
interval
The advertisement interval configured on the VRRP master.
Master down
interval
The down interval configured on the VRRP master
(This interval is used by all the routers in the group regardless of their local settings)
Console#show vrrp brief
Interface Grp State Virtual addr Int Pre Prio
----------------------------------------------------------------
vlan 1 1 Master 192.168.1.6 5 E 1
Console#
