Link Layer Discovery Protocol

12-12

Web – Click LLDP, Device Statistics.

Figure 12-9 LLDP Device Statistics

CLI – This example displays LLDP statistics received from all LLDP-enabled remote

devices connected directly to this switch.

switch#show lldp info statistics 32-18

LLDP Device Statistics

Neighbor Entries List Last Updated : 2450279 seconds

New Neighbor Entries Count : 1

Neighbor Entries Deleted Count : 0

Neighbor Entries Dropped Count : 0

Neighbor Entries Ageout Count : 0

Interface | NumFramesRecvd NumFramesSent NumFramesDiscarded

--------- + -------------- ------------- ------------------

Eth 1/1 | 10 11 0

Eth 1/2 | 0 0 0

Eth 1/3 | 0 0 0

Eth 1/4 | 0 0 0

Eth 1/5 | 0 0 0
