VLAN Commands
34-22
34
- If the frame is untagged but the protocol type does not match, the frame is
forwarded to the default VLAN for this interface.
Example
The following example maps the traffic entering Port 1 which matches the protocol
type specified in protocol group 1 to VLAN 2.
show protocol-vlan protocol-group
This command shows the frame and protocol type associated with protocol groups.
Syntax
show protocol-vlan protocol-group [group-id]
group-id - Group identifier for a protocol group. (Range: 1-2147483647)
Default Setting
All protocol groups are displayed.
Command Mode
Privileged Exec
Example
This shows protocol group 1 configured for IP over Ethernet:
show interfaces protocol-vlan protocol-group
This command shows the mapping from protocol groups to VLANs for the selected
interfaces.
Syntax
show interfaces protocol-vlan protocol-group [interface]
interface
• ethernet unit/port
- unit - Stack unit. (Range: 1-8)
- port - Port number. (Range: 1-26/50)
• port-channel channel-id (Range: 1-32)
Default Setting
The mapping for all interfaces is displayed.
Console(config)#interface ethernet 1/1
Console(config-if)#protocol-vlan protocol-group 1 vlan 2
Console(config-if)#
Console#show protocol-vlan protocol-group
ProtocolGroup ID Frame Type Protocol Type
------------------ ------------- ---------------
1 ethernet 08 00
Console#
