Configuring Interface Settings
10-15
10
forwarding database to reduce the amount of frame flooding required to rebuild
address tables during reconfiguration events, does not cause the spanning tree to
initiate reconfiguration when the interface changes state, and also overcomes
other STA-related timeout problems. However, remember that Edge Port should
only be enabled for ports connected to an end-node device. (Default: Disabled)
• Migration – If at any time the switch detects STP BPDUs, including Configuration
or Topology Change Notification BPDUs, it will automatically set the selected
interface to forced STP-compatible mode. However, you can also use the Protocol
Migration button to manually re-check the appropriate BPDU format (RSTP or
STP-compatible) to send on the selected interfaces. (Default: Disabled)
Web – Click Spanning Tree, STA, Port Configuration or Trunk Configuration. Modify
the required attributes, then click Apply.
Figure 10-6 STA Port Configuration
CLI – This example sets STA attributes for port 7.
Console(config)#interface ethernet 1/7 27-1
Console(config-if)#no spanning-tree spanning-disabled 33-11
Console(config-if)#spanning-tree port-priority 0 33-13
Console(config-if)#spanning-tree cost 50 33-12
Console(config-if)#spanning-tree link-type auto 33-15
Console(config-if)#no spanning-tree edge-port 33-13
Console(config-if)#spanning-tree protocol-migration 33-17
Console(config-if)#
