IP Routing
19-18
19
Web - Click IP, Statistics, ICMP.
Figure 19-9 ICMP Statistics
CLI - See the example on page 19-14.
Destination Unreachable The number of ICMP Destination Unreachable messages received/sent.
Time Exceeded The number of ICMP Time Exceeded messages received/sent.
Parameter Problems The number of ICMP Parameter Problem messages received/sent.
Source Quenches The number of ICMP Source Quench messages received/sent.
Redirects The number of ICMP Redirect messages received/sent.
Echos The number of ICMP Echo (request) messages received/sent.
Echo Replies The number of ICMP Echo Reply messages received/sent.
Timestamps The number of ICMP Timestamp (request) messages received/sent.
Timestamp Replies The number of ICMP Timestamp Reply messages received/sent.
Address Masks The number of ICMP Address Mask Request messages received/sent.
Address Mask Replies The number of ICMP Address Mask Reply messages received/sent.
Table 19-4 ICMP Statistics (Continued)
Parameter Description
