26-1
Chapter 26: Access Control List Commands
Access Control Lists (ACL) provide packet filtering for IPv4 frames (based on
address, protocol, Layer 4 protocol port number or TCP control code), IPv6 frames
(based on address, next header type, or flow label), or any frames (based on MAC
address or Ethernet type). To filter packets, first create an access list, add the
required rules, and then bind the list to a specific port. This section describes the
Access Control List commands.
IPv4 ACLs
The commands in this section configure ACLs based on IPv4 addresses, TCP/UDP
port number, protocol type, and TCP control code. To configure IPv4 ACLs, first
create an access list containing the required permit or deny rules, and then bind the
access list to one or more ports
Table 26-1 Access Control List Commands
Command Groups Function Page
IPv4 ACLs Configures ACLs based on IPv4 addresses, TCP/UDP port number,
protocol type, and TCP control code
26-1
IPv6 ACLs Configures ACLs based on IPv6 addresses, next header type, and flow
label
26-7
MAC ACLs Configures ACLs based on hardware addresses, packet format, and
Ethernet type
26-12
ACL Information Displays ACLs and associated rules; shows ACLs assigned to each port 26-16
Table 26-2 IPv4 ACL Commands
Command Function Mode Page
access-list ip Creates an IPv4 ACL and enters configuration mode for
standard or extended IPv4 ACLs
GC 26-2
permit, deny Filters packets matching a specified source IPv4 address IPv4-
STD-ACL
26-2
permit, deny Filters packets meeting the specified criteria, including
source and destination IPv4 address, TCP/UDP port
number, protocol type, and TCP control code
IPv4-
EXT-ACL
26-3
show ip access-list Displays the rules for configured IPv4 ACLs PE 26-5
ip access-group Adds a port to an IPv4 ACL IC 26-6
show ip access-group Shows port assignments for IPv4 ACLs PE 26-6
