Edge-Core ES4626F User Manual

Configuring Rate Limits
8-21
8
Web - Click Port, Rate Limit, Input/Output Port/Trunk Configuration. Set the Input
Rate Limit Status or Output Rate Limit Status, then set the rate limit for the individual
interfaces, and click Apply.
Figure 8-11 Rate Limit Configuration
CLI - This example sets the rate limit for input and output traffic passing through
port 1 to 600 Mbps.
Console(config)#interface ethernet 1/1 27-1
Console(config-if)#rate-limit input 600 30-1
Console(config-if)#rate-limit output 600
Console(config-if)#

Edge-Core ES4626F Specifications

General

Model	ES4626F
Ports	26
Gigabit Ports	24
Power Supply	AC 100-240V, 50-60Hz
Switching Capacity	128 Gbps
Forwarding Rate	95.2 Mpps
MAC Address Table Size	16K
Redundant Power Supplies	Optional
Storage Humidity	5% to 95% (non-condensing)
Layer	L3
Dimensions	440 x 44 x mm
Management	CLI, Web, SNMP
Jumbo Frame Support	9K
Dimensions (W x D x H)	440 x 44 mm
Operating Temperature	0°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% (non-condensing)
