Priority Commands (Layer 3 and 4)

35-13

show map ip dscp

This command shows the IP DSCP priority map.

Syntax

show map ip dscp [interface]

interface

• ethernet unit/port

- unit - Stack unit. (Range: 1-8)

- port - Port number. (Range: 1-26/50)

• port-channel channel-id (Range: 1-32)

Command Mode

Privileged Exec

Example

Related Commands

map ip dscp (Global Configuration) (35-10)

map ip dscp (Interface Configuration) (35-10)

Console#show map ip dscp ethernet 1/1

DSCP mapping status: disabled

Port DSCP COS

--------- ---- ---

Eth 1/ 1 0 0

Eth 1/ 1 1 0

Eth 1/ 1 2 0

Eth 1/ 1 3 0

Eth 1/ 1 61 0

Eth 1/ 1 62 0

Eth 1/ 1 63 0

Console#
