show lldp info local-device

32-15

show lldp info local-device

This command shows LLDP global and interface-specific configuration settings for

this device.

Syntax

show lldp info local-device [detail interface]

• detail - Shows detailed information.

• interface

• ethernet unit/port

- unit - Stack unit. (Range: 1-8)

- port - Port number. (Range: 1-26/50)

• port-channel channel-id (Range: 1-32)

Command Mode

Privileged Exec

Console#show lldp config detail ethernet 1/1

LLDP Port Configuration Detail

Port : Eth 1/1

Admin Status : Tx-Rx

Notification Enabled : True

Basic TLVs Advertised:

port-description

system-name

system-description

system-capabilities

management-ip-address

802.1 specific TLVs Advertised:

*port-vid

*vlan-name

*proto-vlan

*proto-ident

802.3 specific TLVs Advertised:

*mac-phy

*poe

*link-agg

*max-frame

Console#
