Displaying the Address Table

9-3

Web – Click Address Table, Dynamic Addresses. Specify the search type (i.e., mark

the Interface, MAC Address, or VLAN checkbox), select the method of sorting the

displayed addresses, and then click Query.

Figure 9-2 Dynamic Addresses

CLI – This example also displays the address table entries for port 1.

Console#show mac-address-table interface ethernet 1/1 31-3

Interface Mac Address Vlan Type

--------- ----------------- ---- -----------------

Eth 1/ 1 00-E0-29-94-34-DE 1 Permanent

Eth 1/ 1 00-20-9C-23-CD-60 2 Learned

Console#
