Link Layer Discovery Protocol

12-14

CLI – This example displays detailed LLDP statistics for an LLDP-enabled remote

device attached to a specific port this switch.

switch#show lldp info statistics detail ethernet 1/1 32-18

LLDP Port Statistics Detail

PortName : Eth 1/1

Frames Discarded : 0

Frames Invalid : 0

Frames Received : 12

Frames Sent : 13

TLVs Unrecognized : 0

TLVs Discarded : 0

Neighbor Ageouts : 0

switch#
