7.3.6 Edit a saved alignment job
1. From the Laser Align Application main menu, press ALT > F9 Job Manager.
The Job Manager screen is displayed.
2.
Press F10 or F11 to select a job.
3. Press F3 Edit This Job to edit the job setup of the selected alignment job.
a. Press F2 Edit Job ID, enter a unique ID to identify the job and press Enter.
b. Press F3 Edit Equip ID, enter the equipment ID to identify the equipment being
aligned and press Enter.
c. Press F4 Edit Equip Desc, enter an equipment description to add additional
information on the equipment being aligned and press Enter.
d. Press F5 Edit Area, enter an area description to identify the location of the
equipment being aligned and press Enter.
e. Press F6 Edit Coupling Number, enter the coupling number and press Enter. This
option is useful when there is more than one coupling on the machine being
aligned.
f. Press F7 Set Mode, choose whether the alignment mode is horizontal, vertical, or
straightness and press Enter.
Note
Changing the alignment mode clears all data stored on the job.
g. Press F8 Edit User ID, enter the initials of the user performing the alignment job,
and press Enter.
4.
Press Enter.
7.3.7 Clear an alignment job data
1. Activate an alignment job.
2.
From the Laser Align Application main menu, press ALT > F12 Job Reset.
3. Make sure the Clear Job Data is highlighted and press Enter.
4. Press Yes to delete the alignment data and notes assigned for the job.
7.3.8 Edit a job ID
1. From the Laser Align Application main menu, press ALT > F9 Job Manager.
The Job Manager screen is displayed.
2. Press F10 or F11 to select a job.
3. Press F3 Edit This Job > F2 Edit Job ID.
4. Edit the job ID and press Enter.
Advanced Laser Alignment
186 MHM-97432 Rev 7
