3. Press Enter.
2.12.3 Gestures
You can use gestures rather than pressing the keys to select menu options. The gestures
match the arrows on the corresponding analyzer keys. You can use gestures on all screens
that support the corresponding keys.
Note
You cannot use gestures when the analyzer displays the onscreen keyboard, or when Log is used for
the plot axis. The Enter gesture does not work on plots.
Tip
Use consistent pressure when you press in the middle of the touchscreen as indicated below.
Task Gesture
Activate a plot Touch the desired plot when the analyzer displays multiple
plots.
Add a cursor Touch anywhere on the plot.
Move a cursor Swipe left or right, or touch anywhere on the plot. On a
waveform, the cursor moves 20 percent of the waveform. On
a spectrum, the cursor moves to the next highest peak. To
clear a cursor, use the Clear Cursor option on the plot's ALT
screen.
Increase or decrease the plot
amplitude
Swipe up or down.
Use upper or lower case characters Swipe up or down.
Note
You cannot use gestures for the onscreen keyboard.
Scroll items in a list Swipe up or down. This also applies to the options on the
Balance main menu.
Gestures
Enter Right arrow (swipe right)
Introduction to the analyzer
24 MHM-97432 Rev 7
