2. Set up the job parameters, including balance mode, balance specification, speeds,
tachometers, sensors, measurement planes, measurement points, and weight
planes.
3.
Acquire runout (optional), reference run, and trial run data to calculate the balance
correction.
4. View the calculated balance correction.
5. Acquire trim runs to ensure the machine is within the balance specification based on
your site or the machine manufacturer.
Note
Unless noted, any defaults listed are only used at first. After you modify a field, the Balance program
uses that value until you change it.
Influence coefficient method
The Balance program uses the influence coefficient method to calculate the balance
correction for a machine. The influence coefficient requires both the reference run (as-is)
and trial run data.
10.1.1 Open or close the Balance program
1. To open the Balance program, press F9 Balance from the Home screen.
2.
To close the Balance program, press F7 Exit Balance.
10.1.2 Balance main menu
The Balance main menu lets you monitor your progress through the balance job. An X
displays in the brackets next to each completed step. The analyzer disables other steps
until you complete any prerequisite steps.
Balance
298 MHM-97432 Rev 7
