Option Description
F2 Toggle Config. Repeatedly press F2 until the 2 planes, 2 sensors option appears.
F8 Enter Balance
Spec.
Enter a value between 0.001 and 10,000 for the desired vibration level
for the equipment, and press Enter. The units are the same as the
sensor.
F10 Tach Config. Set up a tachometer or open a saved configuration. See
Set up a tachometer in Balance or
Open a saved tachometer setup in Balance for details.
F12 Sensor Setup Set up the type of sensor, the sensor parameters, or a multiplexer. See
Section 10.4.3 or Section 10.4.5 for details.
3. In Advanced Balance mode, set the following options.
Option Description
F1 Weight Planes Enter a number between 2 and 4, and press Enter.
F2 Meas. Planes Enter a number between 2 and 8, and press Enter.
F3 Meas. Points Enter a number between 2 and 8, and press Enter.
F8 Enter Balance
Spec.
Enter a value between 0.001 and 10,000 for the desired vibration level for
the equipment, and press Enter. The units are the same as the sensor.
F9 Select Weight
Units
(Optional)
Select the trial and trim weight units for the job. The Balance program
displays this unit wherever a weight displays. You cannot change this
value after you acquire any trial run data.
Note
Weight units are only a reference for UltraBal reports or future setups. The
analyzer does not use weight units to calculate the balance correction.
F10 Tach Config. Set up a tachometer or open a saved configuration. See
Set up a tachometer in Balance or Open a saved tachometer setup in Balance
for details.
F11 Speed Setup (Optional)
Enter a number between 1 and 6 to set the number of equipment speeds
(RPM), and set the valid range for collecting data using Delta RPM, which
is used for all speeds. See Section 10.3.5 for steps.
Note
The analyzer does not use speed to calculate the balance correction.
4. From the Job Setup screen, press Enter.
In Basic Balance Mode, the Acquire Data screen appears and you are ready to collect
data. In Advanced Balance Mode, the Measurement Plane Setup screen appears.
Balance
308 MHM-97432 Rev 7
