Postrequisites
In Advanced Balance mode, set up the measurement plane. See Section 10.5.
10.3.4 Tachometers
Set up a tachometer in Balance
By default, the analyzer is setup for CSI 404 tachometers.
Pseudo Tach must be disabled for the Balance program. When the pseudo tach is disabled, a
standard 1x tach is produced.
Note
The CSI 404A and 404B tachometers require power ON if directly connected to the analyzer. If you
connect your tachometer to the 404P external tach power supply, set the power to OFF.
Procedure
1.
From the Balance main menu, press F3 Job Setup > F10 Tach Config > F6 Tach Setup.
The Tachometer Setup screen appears.
2. Set the following options as necessary.
Option Description
F2 Pseudo Tach Disable for the Balance program. When the Pseudo Tach is disabled, a
standard 1x tach is produced.
F5 Tach Power Enable the analyzer to power the tachometer. The default is to provide
power to the tachometer.
F7 Set Trigger Edge Set the trigger to occur on the rising edge or falling edge of a
waveform. The default is Falling Edge.
F8 Set Trigger Level Enter the value between -100 and 100 required to start a tachometer
pulse. For Level measurement, set the input that is the source of the
trigger. The default is 2.0 Volts.
F9 Set Edge Delay Enter the number of seconds between 0 and 16 that occurs between
each tachometer pulse. This helps prevent double triggering. The
default is 0.0 seconds.
F10 Show RPM F10
Hide RPM
View or hide the last RPM the tachometer read and the time between
each reading. A last time value of 0 indicates the tachometer is
continuously reading the RPM.
F12 Set Defaults Restore the default values for all tachometer setup options on the
screen.
3. Press F6 Save / Recall Setup to save the setup, or press Enter to use the setup without
saving it.
Balance
MHM-97432 Rev 7 309
