Page #380 background image
Input sensor types
Portable sensors Accelerometers, velocity probes, RPM/tachometer probes, temperature
sensors, flux coil, current clamp, pressure sensors, triaxial accelerometers,
impact hammer
Installed sensors Any vibration or dynamic sensor with a voltage output; any DC-type signal
Input unit types
Vibration Signals Units
Acceleration g’s
Velocity In/sec or mm/sec
Displacement Mils or microns
Other dynamic
signals
Any user-specified unit
DC Signals Any user-specified unit
Tachometer input
RPM range 1 to 100,000 RPM
Tach input level TTL input, built-in conditioning for non-TTL signals, adjustable trigger level.
The tachometer input measures a once-per-rev pulse to measure RPM.
Advanced acquisitions
PeakVue Selectable filters
Pseudo Tach Generates tach pulses for hidden shafts
Demodulation Selectable filters
Wireless communication
Bluetooth 2.0 Class 2 (optional)
Range up to 10 meters
Wireless 802.11 b/g
Range up to 33 meters
Technical specifications
374 MHM-97432 Rev 7
