The analyzer connects to AMS Machinery Manager, and a new tab with the analyzer
Device ID displays in the Data Transfer tab.
5.
To load a route using AMS Machinery Manager:
a. Select the appropriate database in the Navigator - Data Transfer pane.
b. Drag and drop or copy and paste the desired route to the connected analyzer in
the Data Transfer tab.
The Data Transfer Notification pane displays the progress of the transfer.
6. To load a route using the analyzer:
a. Press F1 Set Storage Location to select internal memory or a SD memory card to
store the route.
b. Press F7 Load Routes.
c. Press F8 or F9 to select a database.
d. Press F10 or F11 to select an area within the database.
e. Press F4 Select Area.
f. Press F8 or F9 to select a route and press F1 Select.
You can select multiple routes.
g. Press F7 Load Route.
If the route is already in the analyzer, an error message appears. Press Enter to
continue and overwrite the existing route. You will lose any data stored in the
existing route.
7. After the transfer completes, press the Back key to disconnect from AMS Machinery
Manager.
3.4.2 Load multiple routes from AMS Machinery Manager to
the analyzer
Load a Multiple Route Load (MRL) file containing multiple routes from an AMS Machinery
Manager database. MRL files help you efficiently load multiple routes at one time. Create a
MRL file in AMS Machinery Manager.
After you load the routes, the analyzer does not group them using the MRL file. The routes
are individual files that you individually transfer back to AMS Machinery Manager after you
collect data.
Note
AMS Standalone Data Transfer cannot transfer MRL files.
Transfer files with CSI 2140
MHM-97432 Rev 7 59
