246 IBM Proprinter Control Commands
SO or ESC SO Enlarged Pitch
ASCII: SO
Control:
CTRL
N
Decimal: 14
Hexadecimal: 0E
ASCII: ESC SO
Control:
CTRL
[
CTRL
N
Decimal: 27 14
Hexadecimal: 1B 0E
Enlarges the currently selected pitch as follows:
Current Pitch After SO or ESC SO
18.2 9.1
17.14 8.57
16.67 8.33
15.0 7.5
12.0 6.0
10.0 5.0
See the BASIC example under DC4.
SO causes the enlarged pitch to remain in effect for one line only, or until
one of the following is received:
•
CR VT SOH A z ! (n)
•
CAN ESC W (0) ESC A z ! (n)
•
LF ESC W (48)
•
FF DC4
Note
: Enlarged pitch is called "Double Wide Printing" by some
manufacturers. This command is not valid when NLQ printing is
selected
.
