Patch 145
Note: When {New} is pressed, the parameter slot will appear in the list with a default
name in the “Parameter” column. You may disregard these default parameters as
you will redefine the designations in a later step.
5. Use the [Page] keys, mouse, or touchscreen to navigate to any parameter slots that you wish
to alter the default parameter designations for.
6. Click on the slot to open a dropdown list of available parameters.
Click on a category to open the dropdown list to see the parameters.
7. Press the desired parameter to assign it.
8. Repeat steps 5 through 7 until you have entered all of the required parameters for the new fix-
ture.
If you aremissing aparameter slot: At any point you can use the [Page] keys and {Insert}, to insert a
parameter slot above the selected one.
If you want to remove aparameter: you can use the [Page] keys and {Delete}, to remove a parameter
from the list.
Define Parameters
Once you have added and specified all of the parameters for the new fixture, you can now define the
address requirements, size, and ranges for each of them.
To definethesize (8-bit or 16-bit), DMX address, and LDMXaddress of any parameter:
You can alter the default DMX address assigned to any parameter in the list. This is not the actual
address that will be used when patched, but rather it is the order of address for the parameter rel-
ative to the other parameters in the fixture.
