Basic Manual Control 175
[1] [Thru] [4] [At] [/] [1] [3] [0][Enter] - scales the intensities of the selected channels in the list
up 30% of their current values. If channels 1 through 4 were at 40% intensity, this would
scale them up by 30% to a value of 52.
[2] [+] [5] [level wheel] - roll the wheel up for greater intensity or down for less intensity.
[1] [Level] - selects channel 1 and sets it to the level as established in Setup.
[Group] [9] [Out] - selects all channels in Group 9 and sets the intensity values for those chan-
nels to zero.
[1] [0] [At] [At] - selects channel 10 and sets an intensity level as established in Setup.
[1] [Full] [Full] - selects channel 1 and sets it to full and self terminates the command line.
[1] [At] [/] [/] [2][3][9] [Enter] - puts channel 1 at DMX value 239.
For Example:
[1] [Thru] [5] [Full] [Enter]
The selected channels are highlighted in gold, with white channel text and red intensity val-
ues (indicating manual data). You may continue to modify channels 1 through 5 since they
are still selected and displayed on the command line.
[-%] [-%]
This command would reduce the intensity of channels 1 through 5 by 20%. This command
is self-terminating.
[At] [7] [5] [Enter]
You can continue manipulating the selected channels so long as the channels are selected and dis-
played on the command line.
Level Wheel
You may set intensity for selected channels or addresses using the level wheel. Rolling the level wheel
upwards increases intensity. Rolling it downwards (towards you) decreases it.
Manual Control of Non-intensity Parameters (NPs)
Non-intensity parameters can be set with a variety of controls including the control keypad, buttons
on the central information area (CIA) and the encoders.
Using the Parameter Display
The parameter display in the CIA is populated with only those parameters that are found in the
patched devices. As channels are selected, the parameter display will change to show only para-
meters relevant to the selected channels.
The parameters are divided into the following categories: Intensity, Focus, Color and Beam. Each
parameter category is represented with buttons in the parameter tiles. These buttons allow you to
select the entire collection of all parameters within that category. You can also select a single para-
meter from a category using that parameter’s button in the parameter display.
