194 Eos Family Operations Manual
Remainder Dim
Note: By default, [Rem Dim] will set to zero. In Setup, you can assign a remainder dim value
of something other than zero. See Manual Control (on page161). For the purposes of this
discussion, the default value of zero will be used in examples.
[Rem Dim] temporarily provides a zero intensity to all channels except those that are currently selec-
ted, those that are parked, or those with intensity contributions from submasters. If the remainder
dim command is reversed, the stage returns to its previous state. You may use the following com-
mands for remainder dim:
[Next] and [Last]- moves through the channel list.
[select channels] [Rem Dim] [Enter] - sets all non-selected channels to zero.
[1] [At] [6] <0> [Rem Dim] [2][0] [Enter] - sets channel 1 to 60% and all non-selected channels
active over 20% to a rem dim level of 20.
[Rem Dim]- clears the rem dim function and returns the stage to its previous state
Pressing [Rem Dim] again releases all channels from rem dim mode and restores the stage to its pre-
vious state. Using the [Next] and [Last] buttons releases the current selected channel from remainder
dim mode and sets its intensity to zero, while selecting the next or last channel and continuing rem
dim operation.
For Example:
Assume channels 5 through 9 are selected and set at an intensity level of 50% and channels
10 through 15 are selected and set at an intensity level of 70%. Select channel 9 and dim
the remaining channels.
[9] [Rem Dim] [Enter]
Channel 9 is set at an intensity level of 50% and all remaining channels are dimmed to zero.
[Next]
Selecting [Next] changes the channel selection to channel 10 which is set at an intensity
level of 70%, the level set in the previous state, and all remaining channels including chan-
nel 9, are dimmed to zero.
[RemDim]
Pressing [Rem Dim] again will return all channels to their previous levels.
[Rem Dim] can be used in groups including the use of [Next] and [Last] buttons to progress through
the channels within the selected group.
For Example:
