Setup 167

Brightness Settings

Note: This screen on Eos allows you to adjust the brightness and contrast settings for the

fader wing LCDs and the light level for desk lamps.

This screen on Eos Ti, Gio, and Gio @ 5 allows you to adjust the brightness and contrast settings for

the fader wing LCDs, the light level for desk lamps, backlit keyboard, the LCD, and direct select

brightness.

This screen on Ion Xe allows you to adjust the brightness and contrast settings for the fader wing

LCDs, the light level for desk lamps, backlit keyboard, and direct select brightness.

This screen on Element 2 allows you to adjust the brightness and contrast settings for the light level

for desk lamps, backlight on the facepanel, and direct select brightness.

Master

The master can be used to set an overall limit to the brightness of the other brightness settings.

Live Master

The brightness of the LCD touchscreens, Littlites, and backlit keyboard can also be controlled by a

live master when outside of the setup display.

By default, the Littlites and backlit keyboard are controlled by the live master. Pressing the {Live

Master} button under the sliders will either include or exclude that item from being controlled. When

the button is highlighted in gray, the item can be controlled by the live master.

The live master is controlled by holding down the [Displays] key and rolling the level wheel.

Desk Lamp

Desk lamps, such as Littlites, can be dimmed from within the software application. The {DeskLamp}

slider has a range of 0% (dimmest) to 100% (brightest). The default setting is 0%. The console will

set the desk lamp to this setting on startup of the application.

The desk lamps can also be controlled by holding down [Displays] and rolling the level wheel if under

{Live Master} control.

Backlit

The brightness of the backlit keys on Eos Ti, Gio, Gio @ 5, and Ion Xe are user-definable. The level

range is from 0 through 100%, with 50% being the default level. On Element 2, this controls the

backlight for the fader position switch.

When the console has been idle for 10 minutes, the backlit keys will fade their intensity down by

10%. Any key press on either the facepanel keyboard, an external keyboard, move of the mouse, or

touch of a touchscreen will return the keys to their set intensity level.

LCD

The brightness level of the LCD touchscreens on Eos Ti and Gio can be adjusted. The range for the

brightness level is 5 through 100%, with 100% being the default level.
