Show Control 529
Note: String MIDI Tx is restricted by {MIDI Cue List} in Setup. See Show Control Settings
(on page495).
Sending UDP Strings
UDP strings will be sent from the console on an ephemeral (always changing) port number to the des-
tination port specified in Setup. UDP strings sent to multicast IP addresses are not supported.
Note: The console can be configured to send either ACN strings or UDP strings, as they
share the String Tx IP Address field. A combination of device names for ACN and IP
addresses for UDP is not supported.
Sending ACN Strings
To send ACN strings, {String TX} must be enabled in Setup>System>Show Control, and the ACN
component name must be set in the {String TX IP Address} field.
For example, the ACN component name could be Paradigm.
If you have multiple devices sending or receiving strings, separate each entry in the {String TX IP
Address}field with a comma.
Note: The console can be configured to send either ACN strings or UDP strings, as they
share the String Tx IP Address field. A combination of device names for ACN and IP
addresses for UDP is not supported.
Sending via the I/O Gateway
For your console to send serial data to a Net3 I/O Gateway, the Serial Port Group ID assigned at the
gateway must match the String TX Group ID in Setup, and String TX setting in Setup must be
Enabled. See Show Control Settings (on page495).
