Programming manual.
CNC 8070
·15·
(REF: 1709)
VERSION HISTORY - CNC 8070
Here is a list of the features added to each manual reference.
Ref. 0201
Ref. 0212
Ref. 0501
Software V01.00
First version. Milling model.
Software V01.10
New repositioning feedrate after tool inspection. • Machine parameter: REPOSFEED.
New treatment of the JOG keys. Different keys to select the axis and the
direction.
• Machine parameter: JOGKEYDEF.
Know the dimensions of the kinematics on an axis. • Variable: (V.)A.HEADOF.xn
Keyboard simulation from the PLC. • Variable: (V.)G.KEY
General scaling factor. • Instruction: #SCALE.
Probe selection. • Instruction: #SELECT PROBE.
Probing canned cycles. • Instruction: #PROBE.
Programming of warnings. • Instruction: #WARNING.
Block repetition. • Instruction: #RPT.
Know the active general scaling factor. • Variable: (V.)G.SCALE
Knowing which is the active probe. • Variable: (V.)G.ACTIVPROBE
Improved programming of high speed machining. • Instruction: #HSC.
Improved programming of axis swapping. • Instructions: #SET
#CALL
#FREE
#RENAME
The number of macros in a program is now limited to 50. • Macros.
Software V02.01
Windows XP operating system.
Emergency shutdown with battery (central unit PC104).
Multi-channel system, up to 4 channels. Swapping of axes and spindles,
communication and synchronization between channels, common arithmetic
parameters, access variables by channel, etc.
Multi-spindle system, up to 4 spindles.
Tool management with up to 4 magazines.
Tool radius compensation mode (G136/G137) by default • Machine parameter: IRCOMP.
New behavior for rotary axes.
The "(V.)TM.MZWAIT " variable is not necessary in the subroutine associated
with M06.
• Subroutine associated with M6.
• Variable: (V.)TM.MZWAIT
Know the software version. • Variable: (V.)G.SOFTWARE
Variables related to loop adjustment. Gain setting via PLC. • Variables: (V.)A.PLCFFGAIN.xn
(V.)A.PLCACFGAIN.xn
(V.)A.PLCPROGAIN.xn
Variables related to loop adjustment. Position increment and sampling period. • Variables: (V.)A.POSINC.xn
(V.)A.TPOSINC.xn
(V.)A.PREVPOSINC.xn
Variables related to loop adjustment. Fine adjustment of feedrate, acceleration
and jerk.
• Variables: (V.)A.FEED.xn
(V.)A.TFEED.xn
(V.)A.ACCEL.xn
(V.)A.TACCEL.xn
(V.)A.JERK.xn
(V.)A.TJERK.xn
Variables related to the feedback inputs. • Variables:
(V.)A.COUNTER.xn
(V.)A.COUNTERST.xn
(V.)A.ASINUS.xn
(V.)A.BSINUS.xn
