Programming manual.
CNC 8070
SUBROUTINES.
14.
Assistance for subroutines.
·285·
(REF: 1709)
14.7.2 List of available subroutines.
The editor allows having in a text file (txt) a list that is displayed while editing the part-program,
every time a #PCALL or an #MCALL instruction is edited.
The editor shows the list of subroutines while editing, after a blank space or tab following
a G180-G189 or following a #PCALL or #MCALL instruction. This list works the same way
as the lists of variables, it is possible to use the arrow keys to scroll through the various
elements. Pressing [ENTER], the editor inserts the selected line in the current position of
the cursor. The list of subroutines disappears with [ESC], deleting the key word or going on
to another line of the program.
This help is always active, regardless of the editing help softkey, "Prog. help".
List of subroutines.
The list of subroutines must be in a text (txt) file. The file must be edited so each line is the
name of a possible subroutine to be called.
Name and location of files.
The name of the file should be pcall.txt.
Where to save the list of subroutines.
The machine manufacturer must save the pcall.txt file in the folder ..\Mtb\Sub\Help. Since
the modifications to the MTB directory in the "User" work mode disappear when turning the
unit off, the user must save his pcall.txt file in the folder ..\Users\Sub\Help.
The CNC looks for the help files in both files; if the files are not there, the CNC will not show
any help. If there is a pcall.txtfile in both directories, the list will show the names of the
subroutines contained in both of them.
Example of a file with a list of subroutines.
C:\CNC8070\USERS\SUB\FAGOR.NC
SUBROUTINE.NC
EXAMPLE.NC
POSITIONING.NC
For versions V1.60 (8060) y V5.60 (8065), the CNC no longer searches for help files in the following
folders.
..\Users\Session\Help\{idioma}
..\Mtb\Sub\Help\{idioma}.
..\Users\Help\{idioma}.
