Fagor 8070 BL - Variables for Setting Zero Offsets

Programming manual.
CNC 8070
ORIGIN SELECTION
5.
Zero offsets (G54-G59/G159)
·89·
(REF: 1709)
5.5.1 Variables for setting zero offsets
Zero offset table (without fine setting of the absolute zero offset).
The following variables may be accessed via part-program or via MDI/MDA mode. Each of
them indicates whether it may be read (R) or written (W).
Zero offset table (with fine setting of the absolute zero offset).
The following variables may be accessed via part-program or via MDI/MDA mode. Each of
them indicates whether it may be read (R) or written (W).
Syntax of the variables.
·ch· Channel number.
·nb· Zero offset number.
·xn· Name, logic number or index of the axis.
Variable. R/W Meaning.
(V.)[ch].A.ORG.xn R Value of the active zero offset (absolute G159 +
incremental G158).
(V.)[ch].A.ADDORG.xn R Value of the active incremental zero offset (G158).
(V.)[ch].A.ORGT[nb].xn R/W Offset set in the zero offset [nb].
Variable. R/W Meaning.
(V.)[ch].A.ORG.xn R Value of the active zero offset (coarse absolute G159 +
fine absolute G159 + incremental G158).
(V.)[ch].A.ADDORG.xn R Value of the active incremental zero offset (G158).
(V.)[ch].A.COARSEORG.xn R Value of the active absolute zero offset (G159), coarse
part.
(V.)[ch].A.FINEORG.xn R Value of the active absolute zero offset (G159), fine part.
(V.)[ch].A.ORGT[nb].xn R/W Offset set in the zero offset [nb]; coarse part plus fine
part. When writing this variable, the value is assigned to
the coarse part deleting the fine part.
(V.)[ch].A.COARSEORGT[nb].xn R/W Offset set in the zero offset [nb]; coarse part.
(V.)[ch].A.FINEORGT[nb].xn R/W Offset set in the zero offset [nb]; fine part.
V.A.ORG.Z Z axis.
V.A.ADDORG.3 Axis with logic number ·3·.
V.[2].A.COARSEORG.3 Axis with index ·3· in the channel ·2·.
V.[2].A.FINEORG.3 Axis with index ·3· in the channel ·2·.
V.A.ORGT[1].Z Zero offset G54 (G159=1). Z axis.
V.A.ORGT[1].Z Zero offset G54 (G159=1). Z axis.
V.A.COARSEORGT[4].3 Zero offset G57 (G159=4). Axis with logic number ·3·.
V.[2].A.FINEORGT[9].3 Zero offset G159=9. Axis with index ·3· in the channel ·2·.
