Programming manual.

CNC 8070

CREATING A PROGRAM.

List of auxiliary (miscellaneous) M functions.

·43·

(REF: 1709)

1.6 List of auxiliary (miscellaneous) M functions.

The following table shows a list of "M" functions available at the CNC. Next to each function,

it indicates which chapter of this manual describes it; if no chapter is indicated, the function

is described in another manual.

Function Meaning

M00 Program stop. 6.6.1

M01 Conditional program stop. 6.6.1

M02 End of program. 1.2.1

M03 Start the spindle clockwise. 7.3

M04 Start the spindle counterclockwise. 7.3

M05 Stop the spindle. 7.3

M06 Tool change. 6.6.1

M17 End of a global or local subroutine. 14.2

M19 Spindle orientation. 7.5

M29 End of a global or local subroutine. 14.2

M30 End of program. 1.2.1

M41 Selects gear ·1·. 7.4

M42 Selects gear ·2·. 7.4

M43 Selects gear ·3·. 7.4

M44 Selects gear ·4·. 7.4
