Programming manual.
CNC 8070
1.
CREATING A PROGRAM.
List of "G" functions.
·42·
(REF: 1709)
G152 * Programming in radius. 3.1
G157 * * Excluding axes in the zero offset. 5.5.3
G158 * * Incremental zero offset. 5.5.2
G159 ! * Additional absolute zero offsets. 5.5
G160 * (·M· model). Multiple machining in a straight line. - - -
G160 * (·T· model). Drilling / tapping canned cycle on the face of the part. - - -
G161 * (·M· model). Multiple machining in rectangular pattern. - - -
G161 * (·T· model). Drilling / tapping canned cycle on the side of the part. - - -
G162 * (·M· model). Multiple machining in a grid pattern. - - -
G162 * (·T· model). Slot milling canned cycle along the side of the part. - - -
G163 * (·M· model). Multiple machining in a circular pattern. - - -
G163 * (·T· model). Slot milling canned cycle along the face of the part. - - -
G164 * (·M· model). Multiple machining in an arc. - - -
G165 * (·M· model). Machining programmed with an arc-chord. - - -
G170 * Hirth axes OFF. 12.3
G171 * * Hirth axes ON. 12.3
G174 * Set the machine coordinate. 5.2
G180
G189
* OEM subroutine execution. 14.5
G380
G399
* OEM subroutine execution. 14.5
G192 * * Turning speed limitation. 7.2.1
G193 * Interpolating the feedrate. 6.2.2
G196 * * Constant surface speed (feedrate at the cutting point). 6.2.3
G197 * * Constant feedrate of the tool center. 6.2.3
G198 Setting of lower software travel limits. 12.2
G199 Setting of upper software travel limits. 12.2
G200 Exclusive manual intervention. 9.2
G201 * Activate additive manual intervention. 9.1
G202 * * Cancel additive manual intervention. 9.1
G210 * * (·M· model). Bore milling canned cycle. - - -
G211 * * (·M· model). Inside thread milling cycle. - - -
G212 * * (·M· model). Outside thread milling cycle. - - -
G233 * * Withdraw the axes after interrupting an electronic threading. 10.4
G261 * * Arc center in absolute coordinates (modal). 8.3.9
G262 * * Arc center referred to starting point. 8.3.9
G263 * * Arc radius programming. 8.3.2
G264 * * Cancel arc center correction. 8.3.11
G265 * * Activate arc center correction. 8.3.11
G266 * Feedrate override at 100%. 6.2.4
G500
G599
* Generic user subroutines. 14.6
Function M D V Meaning
