1.4 Programming of the axes.
Programming using the name of the axis.
The axis name is defined by 1 or 2 characters. The first character must be one of the letters
X - Y - Z - U - V - W - A - B - C. The second character is optional and will be a numerical
suffix between 1 and 9. This way, the name of the spindles may be within the range X,
X1…X9,...C, C1…C9.
The movements are represented by the axis letter followed by the target position for the axis.
For axes like X1, Y2, etc. the "=" sign must be included between the axis name and the
coordinate.
Programming using wild cards.
The axes can also be programmed using wild cards. The wild cards may be used to program
and refer to the axes of the channel using their position in it, including the empty spaces.
The wild card is represented by the "?" character followed by the position number of the axis,
?1 for the first axis, ?2 for the second one, and so forth. If the position of a gap is programmed,
the CNC will display an error message.
Using these wild cards, the user can program a movement as follows.
Besides for programming movements, the wild cards can also be used to refer to the axes
in the following G functions and instructions.
X100
Z34.54
X2=123.4
A5=78.532
In a channel with the following distribution of axes,
the wild cards refer to the following axes.
• The ?1 wild card corresponds to the Y axis.
• The ?2 wild card corresponds to the X axis.
• The ?3 wild card issues an error, there is no
axis in that position.
• The ?4 wild card corresponds to the Z axis.
?1 = 12345.1234
?2 = 50.34
G functions. Instructions.
G14
G45
G74
G92
G100
G101
G112
G130
G132
G134
G135
G145
G158
G170
G171
G198
G199
#MOVE ABS
#MOVE ADD
#MOVE INF
#CAM ON
#CAM OFF
#FOLLOW ON
#FOLLOW OFF
#TOOL AX
#LINK
#UNLINK
#PARK
#UNPARK
#SERVO ON
#SERVO OFF
Y
X
?
Z
00000.0000
00000.0000
* * * * .* * * *
00000.0000
